VLT Micro Drive FC 51
4.1.3. 0-32 Custom Readout Max Scale
0-32 Custom Readout Max Scale
Range:
*
100.0 [0.00 – 9999.00]
4.1.4. 0-4* LCP Keypad
The frequency converter can operate in the following three modes:
Hand:
The frequency converter is locally operated and does not allow any remote control. By activating Hand a start signal is given.
OFF: The frequency converter stops with a normal stop ramp. When Off is chosen the frequency converter can only be started by pressing either Hand
or Auto on the LCP.
Auto:
In Auto-mode the frequency converter can be remote controlled (bus/digital).
0-40 [Hand on] Key on LCP
Option:
[0] Disabled
* Enabled
[1 ]
0-41 [Off/Reset] Key on LCP
Option:
[0] Disable Off/Reset
* Enable Off/Reset
[1 ]
[2] Enable Reset Only
0-42 [Auto on] Key on LCP
Option:
[0] Disabled
Enabled
*
[1 ]
4.1.5. 0-5* Copy/Save
0-50 LCP Copy
Option:
[1] All to LCP
[2] All from LCP
[3] Size indep. from LCP
0-51 Set-up Copy
Option:
Function:
It is possible to create a customized readout related to the output frequency of the unit. The value entered in
par. 0-32 will be shown at the frequency programmed in par. 4-14 Motor Speed High Limit. The readout can be
shown in the LCP display when in Status Mode or it can be read in par. 16-09
Hand Off
, and
Function:
Hand-on key has no function.
Hand-on key is functional.
Function:
Off/reset key has no function.
Stop signal and reset of any faults.
Reset only. Stop (Off) function is disabled.
Function:
Auto-on key has no function.
Auto-on key is functional.
Function:
The detachable LCP of the frequency converter can be used for storing setups, and thus for transferring data
when moving parameter settings from one frequency converter to another.
NB!
LCP Copy
can only be activated from the LCP and ONLY when the motor is coasted.
Copy all setups from the frequency converter into the LCP.
Copy all setups from LCP to frequency converter.
Copy non motor size dependent data from LCP to frequency converter
Function:
Use this function to copy a set-up content into the
In order to be able to make a set-up copy ensure that
• the motor is coasted
• par. 0-10, Active Set-up , is set to either
MG.02.C4.02 - VLT is a registered Danfoss trademark
4. Parameter Descriptions
Auto
.
Edit Set-up .
Set-up 1 [1] or Set-up 2 [2]
