Configuration - continued
Configuration of inputs
and outputs
1. Go to Configuration menu
2. Select I/O configuration
3. Configuration of Digital outputs
Press the +-button to go on to the
next page
4. Setup On/off inputs
Press the +-button to go on to
the next page.
AK-PC 783
The following displays will depend on the earlier definitions. The dis-
plays will show which connections the earlier settings will require. The
tables are the same as shown earlier.
• Digital outputs
• Digital inputs
• Analog outputs
• Analog inputs
Load
Solenoid valve, oil, Comp. 1 LT
Solenoid valve, oil, Comp. 2 LT
Solenoid valve, oil separator
Solenoid valve, cascade
EC motor ON/OFF signal
Compressor 1, MT
Compressor 2, MT
Compressor 3. MT
Compressor 4, MT
Compressor 1, LT
Compressor 2, LT
We set up the controller's digital outputs by keying in which module
and point on this module each one of these has been connected to.
We furthermore select for each output whether the load is to be active
when the output is in pos. ON or OFF.
Function
Level switch, oil, comp.1 LT
Level switch, oil, comp.2 LT
Level switch, oil, receiver High
Level switch, oil, receiver Low
Level switch, oil, Separator High
Reset of compressor stop
Compressor 1 Gen. Safety MT
Compressor 2 Gen. Safety MT
Compressor 3 Gen. Safety MT
Compressor 4 Gen. Safety MT
All compressors common safety MT
All compressors common safety LT
Compressor 1 Gen. Safety LT
Compressor 2 Gen. Safety LT
We set up the controller's digital input functions by keying in which
module and point on this module each one of these has been connected
to.
We furthermore select for each output whether the function is to be ac-
tive when the output is in pos. Closed or Open.
Open has been selected here for all the safety circuits. This means that
the controller will receive signal under normal operation and register it
as a fault if the signal is interrupted.
Capacity controller RS8GN202 © Danfoss 11-2013
Output
Module
Point
Active at
DO1
1
12
DO2
1
13
DO5
1
16
D06
1
17
DO7
1
18
DO1
2
1
DO2
2
2
DO3
2
3
DO4
2
4
DO5
2
5
DO6
2
6
Input
Module
Point
Active at
AI8
1
8
AI9
1
9
AI1
3
1
AI2
3
2
AI3
3
3
Pulse pres-
AI5
3
5
sure
DI1
4
1
DI2
4
2
DI3
4
3
DI4
4
4
DI5
4
5
DI6
4
6
DI7
4
7
DI8
4
8
3 - Outputs
The possible functions are
the following:
Comp. 1
Unloader 1-1
Unloader 1-2
Unloader 1-3
Do for Compressor. 2-4
Oil valve comp. 1-4
Lp comp. oil pulse
ON
Oil valve 1-4
ON
Oil valve separat. 1-4
MT Comp. release
ON
LT Comp. request
ON
Injection heat exchanger
ON
Injection suction line
ON
Injection ON
ON
Fan 1 / VSD
ON
Fan 2 - 8
ON
Heat recovery
Valve tap water V3tw
ON
Pump tap water tw
ON
Valve heat recov. V3hr
Pump heat recov. hr
Alarm
I'm alive relay
Thermostat 1 - 3
Pressostat 1 - 3
Volt input 1 - 3
PI 1-3
4 - Digital inputs
The possible functions are
the following:
Ext. Main switch
Ext. compr. stop
Ext. power loss
Night setback
Load shed 1
Load shed 2
All compressors:
Common safety
Comp. 1
Oil pressure safety
Over current safety
Closed
Motor protect. safety
Disch. temp. safety
Closed
Disch. press. safety
Closed
General safety
Closed
VSD comp. 1 Fault
Closed
Do for Comp. 2-4
Fan 1 safety
Do for fan 2-4
VSD cond safety
Open
Reset comp. lockout
Open
LP comp.oil counter
Open
Oil receiver low
Open
Oil receiver high
Open
Oil level comp.1-4
Open
Oil separator low 1-4
Oil separator high 1-4
Open
Heat recovery
Open
tw enable
hr enable
Flow switch tw
Flow switch hr
DI 1 Alarm input
DI 2-10 ...
PI-1 Di ref
External DI PI-1
75
