Configuration - continued
5. Configuration of Analog
outputs
Press the +-button to go on to
the next page
6. Configuration of Analog
Input signals
76
Function
Stepper signal for ETS-valve
Speed control, compressor, MT
Speed control, compressor, LT
Speed control, EC motor
Sensor
Disch. gas temperature - Sd-MT
Suction gas temperature - Ss-MT
Outdoor temp - Sc3
Disch. gas temperature - Sd-LT
Suction gas temperature - Ss-LT
Suction pressure - P0-MT
Condenser pressure - Pc-MT
Suction pressure - P0-LT
Condenser pressure - Pc-LT
Temp. heat exchanger Scasc2
Temp. heat exchanger Scasc3
Oil receiver, Prec Oil
Capacity controller RS8GN202 © Danfoss 11-2013
Output
Module
Point
Type
Step 1
3
9
Steppes
AO1
5
5
AO2
5
6
AO3
5
7
Input
Module
Point
Type
AI1
1
1
Pt 1000
AI2
1
2
Pt 1000
AI3
1
3
Pt 1000
AI4
1
4
Pt 1000
AI5
1
5
Pt 1000
AI6
1
6
AKS 32R-12
AI7
1
7
AKS 32R-34
AI7
3
7
AKS 2050-59
AI8
3
8
AKS 2050-59
AI1
5
1
Pt 1000
AI2
5
2
Pt 1000
AI4
5
4
AKS 2050-59
5 - Analog outputs
The possible signals are
the following:
0 -10 V
2 – 10 V
0 -5 V
0 - 10 V
1 – 5V
0 - 10 V
Stepper output
0 - 10 V
Stepper output 2
6 - Analog inputs
The possible signals are
the following:
Temperature sensors:
• Pt1000
• PTC 1000
Pressure transmitters:
• AKS 32, -1 – 6 bar
• AKS 32R, -1 – 6 bar
• AKS 32, - 1 – 9 bar
• AKS 32R, -1 – 9 bar
• AKS 32, - 1 – 12 bar
• AKS 32R, -1 – 12 bar
• AKS 32, - 1 – 20 bar
• AKS 32R, -1 – 20 bar
• AKS 32, - 1 – 34 bar
• AKS 32R, -1 – 34 bar
• AKS 32, - 1 – 50 bar
• AKS 32R, -1 – 50 bar
• AKS 2050, -1 – 59 bar
• AKS 2050, -1 – 99 bar
• AKS 2050, -1 – 159 bar
• User defined (only
ratiometric, min. and max
value of the pressure
range must be set)
S4 Cold brine
Pctrl
Po suction pres.
Ss suction gas
Sd disch. temp.
Pc Cond. Pres.
S7 Warm brine
Sc3 air on
Ext. Ref. Signal
• 0 – 5 V,
• 0 -10 V
Olie receiver
Prec
Stw2,3,4,8
Shr2,3,4,8
HC 1-5
Heat recovery
Saux 1 - 4
Paux 1 - 3
Voltage input 1 - 5
• 0 -5 V,
• 0 -10 V,
• 1 – 5 V,
• 2 – 10 V
PI-in temp
PI-ref temp
PI- in voltage
PI-in pres.
PI-ref pres.
AK-PC 783
