Wiring

Decide during planning which function is to be connected and
where this will be.
1. Connect inputs and outputs
Here are the tables for the example:
Signal Module
Discharge gas temperature - Sd-MT
Suction gas temperature - Ss-MT
Outdoor temperature - Sc3
Discharge gas temperature - Sd-LT
Suction gas temperature - Ss-LT
Suction pressure - P0-MT
Condenser pressure - Pc-MT
Level switch, oil, comp. 1 LT
Level switch, oil, comp..2 LT
Solenoid valve, oil, Comp. 1 LT
Solenoid valve, oil, Comp. 2 LT
Solenoid valve , oil, Separator
Solenoid valve, cascade
EC motor on/off signal
Signal Module
Compressor 1 MT
Compressor 2 MT
Compressor 3 MT
Compressor 4 MT
Compressor 1 LT
Compressor 2 LT
Signal Module
Level switch, oil, receiver High
Level switch, oil, receiver Low
Level switch, oil, Separator, High
Pulse reset of stopped compressor
3
Suctioon pressure - P0-LT
Condenser pressure - Pc-LT
Stepper signal til ETS valve
48
Point Signal type /
Terminal
1 (AI 1) 1 - 2
Pt 1000
2 (AI 2) 3 - 4 Pt 1000
3 (AI 3) 5 - 6 Pt 1000
4 (AI 4) 7 - 8
Pt 1000
5 (AI 5) 9 - 10 Pt 1000
6 (AI 6) 11 - 12 AKS 32R-12
7 (AI 7) 13 - 14 AKS 32R-34
8 (AI 8) 19 - 20 closed
9 (AI 9) 21 - 22
closed
10 (AI 10) 23 - 24
1
11 (AI 11) 25 - 26
12 (DO 1) 31 - 32
ON
13 (DO 2) 33 - 34
ON
14 (DO 3) 35 - 36
15 (DO 4) 37 - 38
16 (DO 5) 39 - 40 - 41
ON
17 (DO6) 42 - 43 - 44 ON
18 (DO7) 45 - 46 - 47 ON
19 (DO8) 48 - 49 - 50
24 -
25 -
Point Signal type /
Terminal
1 (DO 1) 25 - 26 - 27 ON
2 (DO 2) 28 - 29 - 30 ON
3 (DO 3) 31 - 32 - 33
ON
4 (DO 4) 34 - 35 - 36
ON
2
5 (DO 5) 37 - 38 - 39
ON
6 (DO6) 40 - 41 - 42 ON
7 (DO7) 43 - 44 - 45
8 (DO8) 46 - 47 - 48
Point/Step Terminal Signal type
1 (AI 1) 1 - 2 Closed
2 (AI 2) 3 - 4 Closed
3 (AI 3) 5 - 6
Closed
4 (AI 4) 7 - 8
5 (AI 5) 9 - 10
6 (AI 6) 11 - 12 Pulse
7 (AI 7) 13 - 14 AKS 2050-59
8 (AI 8) 15 - 16
AKS 2050-59
1 (AO 1) 25 - 26 - 27 - 28 ETS
2 (AO 2) 29 - 30 - 31 - 32
3 (AO 3) 33 - 34 - 35 - 36
4 (AO 4) 37 - 38 - 39 - 40
Capacity controller RS8GN202 © Danfoss 11-2013
Remember the isolation amplifier
If signals are received from different controls, e.g. heat re-
covery for one of the inputs, a galvanically insulated module
should be inserted.
Active at
The function of the switch functions can be seen in the last column.
There are pressure transmitters AKS 32R and AKS 2050 available for
several pressure ranges.
Here there are three different ones. One up to 12 bar, 34 bar and 59 bar.
Signal
Active at
Compressor 1 Gen. Safety MT
Compressor 2 Gen. Safety MT
Compressor 3 Gen. Safety MT
Compressor 4 Gen. Safety MT
All compressors common safety MT
All compressors common safety LT
Compressor 1 Gen. Safety LT
Compressor 2 Gen. Safety LT
Signal
Temp. heat exchanger Scasc2
Temp. heat exchanger Scasc3
Oil receiver, Prec Oil
Speed control, compressor MT
Speed control, compressor LT
Speed control, EC motor
Module Point Terminal
1 (DI 1) 1 - 2
2 (DI 2) 3 - 4
3 (DI 3) 5 - 6
4 (DI 4) 7 - 8
4
5 (DI 5) 9 - 10
6 (DI 6) 11 - 12
7 (DI 7) 13 - 14
8 (DI 8) 15 - 16
Module Point Terminal
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5
5 (AO 1) 9 - 10
6 (AO 2) 11 - 12
7 (AO 3) 13 - 14
8 (AO 4) 15 - 16
Active at
Open
Open
Open
Open
Open
Open
Open
Open
Signal type
Pt 1000
Pt 1000
AKS 2050-59
0 - 10 V
0 - 10 V
0 - 10 V
AK-PC 783
