HFX Product Family
HFX12m & HF20m Dimensional Data
11.2
RECOMMENDED WIRING PRACTICES
This section contains information about the controller
connectors and pin outs. Please use the following
recommended wiring practices when installing and using the
controller:
Ensure correct and adequate single point ground to
•
prevent ground loops.
Use twisted or twisted shielded pair cable for CAN
•
per the applicable standard.
Con rm that the CAN network is properly terminated
•
using 120 resistors.
Ensure the appropriate sized conductor cross section is
speci ed for the intended load current in the harness
design.
16
HFX Product Family Installation and Operation Manual for C-API April 2017
4X .256
6.50
4.654
118.22
5.144
130.67
5.756
146.21
Note: Please review individual overcurrent shutdown values
in the con guration and use the correct wire
conductor to accommodate maximum load current
con gured
Make sure that voltage drops are kept within reasonable
•
levels under maximum continuous load conditions e.g. 1
volt on 12-volt systems and 2 volts on 24 - volt systems.
Verify that the harness is constructed to meet the needs
•
of the application environment
(e.g. shock, vibration, moisture, temperature, chemicals,
5.282
and impact).
134.17
Make certain that the harness is designed and constructed
•
to minimize induced interference resulting from EMI
coupling between signal wires.
Separate power circuits from low - level signals.
•
All splices (soldered or crimped) should use adhesive
•
lined heat shrink tubing.
Make provisions for drip loops to attach devices in
•
exposed locations and prevent moisture entry and
formation.
Provide su cient clearance from moving parts.
•
Wires routed through holes in the vehicle body/chassis
•
should use grommets.
2X 2.305
Avoid sharp metal edges, fasteners, and other abrasive
58.55
•
surfaces or use protective shielding when routing harness
assembly.
Route wires to avoid exhaust system components or other
4X .379
•
high temperature areas, use appropriate heat shielding or
9.61
other insulation where routing is a problem.
Avoid routing near wheel wells or provide adequate
•
mechanical protection to the assembly.
Use a protective fuse sized appropriately for the
•
2.305
controller supply current.
58.55
Note: typical maximum load current is 60% - 80% of fuse
rating. Verify that wiring can handle more current than the
fuse rating. Note the following guideline for maximum
fuse recommendations:
4X .379
9.61
All Units: +VBat = 2 A
•
HFX48 :+Load total < 50 A depending upon anticipate d
•
load requirements.
HFX32: +Load total < 42 A depending upon anticipated
•
load requirements.
HFX20: +Load total < 34 A depending upon anticipated
•
load requirements.
HFX12: +Load total < 26 A depending upon anticipated load
•
requirements.
! Warning: Prior to Welding
In order to avoid damaging the HFX controller ensure that all electrical
connectors are fully disconnected from the HFX controller prior to
welding on the machine.
gauge
