BCE-GENTRX32-001 Programming Setup

Step 1. Hardware: Obtain the e-Writer 32 and e-Socket (ESKT32ICPB) from Holtek.
Step 2. Software: Download the HOPE3000F programmer software or HT32 from the
Step 3. Connect V
AN0519E V1.00
Figure 10. e-Socket (ESKT32ICPB)
Holtek website:
http://www.holtek.com.tw/documents/10179/187116/HOPE3000ForHT32V206Bu
ild20181023Install.zip
to V .
IN OUT
Figure 11. e-Socket Power Connection
4 / 7
RF Module Generic Development
Board Programming Firmware Manual
Figure 9. e-Writer 32
