Step 4. Connect the e-CON12A port to the BCE-GENTrx8-001 firmware download port
using a 12-pin cable.
Step 5. Connect the e-Writer Pro to the computer using a USB cable. Start the
HOPE3000 software and then click the "File" followed by "Open and Download"
icons to select a desired programming file. After this a package select dialog will
pop up. Select the "ICP(e-CON12A) 3V) item shown in Figure 7.
Step 6. Execute the programming operations using the HOPE3000 programming user
interface.
AN0519E V1.00
RF Module Generic Development
Board Programming Firmware Manual
Figure 5. 12-pin Cable Connection
Figure 6. Load an 8-bit Programming File
Figure 7. Package Select Dialog
Figure 8. HOPE3000 Programming User Interface
