Data type
Time Time
Field n bytes
Domain C-declaratione: unsigned
char x[n]
String
String
(Zero terminated string)

10.3 Communication status

Communication object number:
24571
Operation:
Read only
Data type:
Binary32
Meaning:
Bit 0 Internal terminal in InteliSys does not work (0 for other controllers).
IGS-NT Communication Guide
Number of
Meaning
registers
2
n
depends on
register number
Data part of the communication function
LSB2 = 0
example:
MSB1 = 18 (HEX)
LSB1 = 04 (HEX)
MSB2 = 01 (HEX)
LSB2 = 0
→ Date = 18.4.(20)01
MSB1 = BCD(hour)
LSB1 = BCD(minute)
MSB2 = BCD(second)
LSB2 = 0
example:
MSB1 = 20 (HEX)
LSB1 = 24 (HEX)
MSB2 = 02 (HEX)
LSB2 = 0
→ Time = 20:24:02
MSB1 = x[0]
LSB1 = x[1]
MSB2 = x[2]
LSB2 = x[3]
...
n is even number:
MSBm-1 = x[n-2]
LSBm = x[n-1]
n is odd number:
MSBm-1 = x[n-1]
LSBm = 0
string characters coding depends on chosen
language (8bit coding, EUC)
