Hardware Installation and Reference Guide
4G signal strength indicators
USB: USB status indicator
FE indicator: LINK/ACT indicator
FE indicator: SPEED indicator
WiFi status indicator

1.1.4 Specifications

RSR10-01G-T(W)-I V2.00
Item
FE Port 5
USB Port 1
3G/4G Port Supporting four modes (TD-LTE, FDD-LTE, WCDMA, and GSM)
WiFi Port 802.11b/g/n 2X2
Processor High-performance RISC network processor
DDR3 RAM 512 MB
Boot ROM 2 MB
Nand Flash 128 MB
Dimensions
121 mm x 101 mm x 44 mm
(W x H x D)
Input Voltage Input of the power adapter: 90–264 V AC; 47/63 Hz
Power
< 6 W
Consumption
Operating
-20° C to 60° C
Temperature
Storage
-40° C to 85° C
Temperature
All indicators off: There is basically no radio signal, and the wireless network
is unavailable.
One indicator on: The signal is poor.
Two indicators on: The signal is good.
Three indicators on: The signal is excellent.
Off: The USB device is not inserted.
Solid green: The USB device is properly identified.
On: The link is properly connected.
Off: The link is disconnected.
Blinking: The link is sending or receiving data.
On: The port is connected at 100 Mbps.
Off: The port is connected at 10 Mbps.
On: The WiFi function is operational.
Off: The WiFi function is not operational.
