Pin number
1
2
3
7.13

TFT LCD connector CN15

A TFT-color LCD with MIPI DSI interface board is mounted on CN15. Refer to
devices for details.
7.14

USB OTG1_FS Micro-AB connector CN16

Pin number
1
2
3
7.15

Audio jack CN17

A 3.5 mm stereo audio jack CN17 is available on the STM32H7x7I-EVAL Evaluation board to support headset
(headphone and microphone integrated).
7.16

USB OTG2_FS Micro-AB connector CN18

UM2525 - Rev 3
Table 30. USB OTG1_HS Micro-AB connector CN14
Description
V
BUS
D-
D+
Figure 15. USB OTG1_FS Micro-AB connector CN16 (front view)
Table 31. USB OTG1_FS Micro-AB connector CN16
Description
VBUS (PB13)
D- (PB14)
D+ (PB15)
Figure 16. USB OTG2_FS Micro-AB connector CN18 (front view)
TFT LCD connector CN15
Pin number
4
5
-
Section 6.19 Display and input
Pin number
4
5
-
UM2525
Description
ID
GND
-
Description
ID (PB12)
GND
-
