Display and input devices

Four general-purpose-color LEDs (LD 1, 2, 3 and 4) are available as display device.
The 4-direction joystick (B4) with selection, Wakeup (B2) and Tamper/key button (B3) are available as input
devices.
A 4" 800x480 TFT color LCD with capacitive touch panel is connected to the MIPI DSI interface of the
STM32H7x7XI microcontroller.
Pin number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
UM2525 - Rev 3
Table 16. LCD module connector (CN15)
Description Pin connection
GND -
DSI_CK_P -
DSI_CK_N -
GND -
DSI_D0_P -
DSI_D0_N -
GND -
DSI_D1_P -
DSI_D1_N -
GND -
BLVDD(5V) -
BLVDD(5V) -
- -
BLGND -
BLGND -
- -
- -
SCLK/MCLK PE5
LRCLK PE4
I2S_DATA PE6
- -
- -
CEC_CLK PA8
CEC PA15
DSI_TE PJ2
- -
BL_CTRL PA6
-
DSI_RESET PF10
-
Pin number Description
2 -
4 TOUCH_INT
6 GND
8 RFU
10 RFU
12 GND
14 RFU
16 RFU
18 GND
20 -
22 -
24 -
26 -
28 -
30 -
32 -
34 -
36 3.3V
38 -
40 I2C1_SDA
42 -
44 I2C1_SCL
46 -
48 -
50 -
52 -
54 -
56 -
58 -
60 1.8V
UM2525
Display and input devices
Pin connection
-
MFX GPIO14
-
GND
GND
-
GND
GND
-
-
-
-
-
-
-
-
-
-
-
PB7
PB6
-
-
-
-
-
-
-
-
page 20/69
