Pin Description
25 PE0
27 PG10
29 GND
31 PD0
33 PI2
35 PI1
37 PI0
39 PH13
2 PH7
4 PE5
6 PD6
8 PF2
10 GND
12 PF1
14 PF0
16 PE2
18 PI7
20 PI9
22 PI6
24 PD7
26 PD5
28 PD4
30 GND
32 PD1
34 PI3
36 PH15
38 PH14
40 +3.3V
UM2525 - Rev 3
Alternative function
NBL0
NE3
-
D2
D26
D25
D24
D21
SDCKE1
A21/SAI1_SCK_A/TRACED2
NWAIT
A2
-
A1
A0
A23/PDM1_CK1/ SAI1_MCLK_A /TRACECLK
D29
D30
D28
NE1
NWE
NOE
-
D3
D27
D23
D22
-
Memory connector CN11 and CN12
How to disconnect with function block on
STM32H7x7I-EVAL board
-
-
-
-
-
-
-
-
-
Open SB41, SB42
-
-
-
-
-
Open SB11, SB15, SB57
-
-
-
-
-
-
-
-
-
-
-
-
