Table 28. Memory Connector Cn12 - ST STM32H757I-EVAL User Manual

Pin Description
33 PG2
35 PD8
37 PD9
39 PD14
2 PH5
4 PF14
6 PG0
8 PF11
10 GND
12 PE9
14 PE8
16 PE11
18 PF15
20 PE14
22 PH8
24 PH10
26 PH9
28 PG4
30 GND
32 PH12
34 PG3
36 PD10
38 PD15
40 PG8
Pin Description
1 PF5
3 PF4
5 PF3
7 PE6
9 GND
11 PE4
13 PE3
15 PI5
17 PI4
19 PG15
21 PI10
23 PE1
UM2525 - Rev 3
Alternative function How to disconnect with function block on STM32H7x7I-EVAL board
A12
D13
D14
D0
SDNWE
A8
A10
SDNRAS
-
D6
D5
D8
A9
D11
D16
D18
D17
A14/BA0
-
D20
A13
D15
D1
SDCLK
Table 28. Memory connector CN12
Alternative function
A5
A4
A3
A22/SAI1_SD_A/TRACED3
-
A20/SAI1_FS_A/TRACED1
A19/SAI1_SD_B/TRACED0
NBL3
NBL2
SDNCAS
D31
NBL1
Memory connector CN11 and CN12
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
How to disconnect with function block on
STM32H7x7I-EVAL board
-
-
-
Open SB2, SB3
-
Open SB5, SB7
Open SB8, SB9
-
-
-
-
-
UM2525
page 30/69
