VLT AutomationDrive FC 300 Operating
Instructions
Illustration 3.11: A5, B1,B2, C1 and C2 enclosures

3.3.6. Electrical Installation, Control Terminals

To mount the cable to the terminal:
1.
2.
3.
4.
To remove the cable from the terminal:
1.
2.
1)
Max. 0.4 x 2.5 mm
Assembling of IP55 / NEMA Type 12 (A5 housing) with mains disconnector
Mains switch is placed on left side on B1, B2,
C1 and C2 enclosures. Mains switch on A5 en-
closure is placed on right side
Strip isolation of 9-10 mm
1)
Insert a screw driver in the square
hole.
Insert the cable in the adjacent cir-
cular hole.
Remove the screw driver. The cable
is now mounted to the terminal.
Insert a screw driver 1) in the square
hole.
Pull out the cable.
MG.33.A9.02 - VLT is a registered Danfoss trademark
3. How to Install
2.
3.
1.
3
29
