VLT AutomationDrive FC 300 Operating
Instructions
Frame size
IP
NEMA
Height
Height
back plate
Height
de-coupling
plate
Distance be-
tween
mounting
holes
Width
Width
back plate
Width
back
with one C
option
Width
back
with two C
options
Distance be-
tween
mounting
holes
Depth
Depth with-
out option A/
B
With
A/B
Without op-
tion A/B
With
A/B
Screw
holes
Max weight
* The front of the frequency converter is slightly convex. C is the shortest distance from back to front (i.e. measured
from corner to corner) of the frequency converter. D is the longest distance from back to front (i.e. measured in the
middle) of the frequency converter.
A1
0.25–1.5 kW
(200-240 V)
0.37-1.5 kW
(380-480 V)
20 21
Chassis Type 1
of
A 200 mm
with
A 316 mm
a 190 mm
of
B 75 mm
of
plate
B
of
plate
B
b 60 mm
C 205 mm
option
C 220 mm
D* 207 mm
option
D* 222 mm
c 6.0 mm
d ø8 mm
e ø5 mm
f 5 mm
2.7 kg
MG.33.A9.02 - VLT is a registered Danfoss trademark
Mechanical dimensions
A2
0.25-3 kW (200-240
V) (200-240 V)
0.37-4.0 kW
(380-480/
500 V)
0.75-4 kW
(525-600 V) (525-600 V)
20 21 20
Chassis Type 1 Chassis
268 mm 375 mm 268 mm
- 374 mm 374 mm
257 mm 350 mm 257 mm
90 mm 90 mm 130 mm
130 mm 130 mm 170 mm
150 mm 150 mm 190 mm
70 mm 70 mm 110 mm
205 mm 205 mm 205 mm
220 mm 220 mm 220 mm
207 mm
222 mm
8.0 mm 8.0 mm 8.0 mm
ø11 mm ø11 mm ø11 mm
ø5.5 mm ø5.5 mm ø5.5 mm
9 mm 9 mm 9 mm
4.9 kg 5.3 kg 6.6 kg
3. How to Install
A3 A5
3.7 kW 0.25-3.7 kW
(200-240 V)
5.5-7.5 kW 0.37-7.5 kW
(380-480/ (380-480/
500 V) 500 V)
5.5-7.5 kW 0.75-7.5 kW
(525-600 V)
21 55/66
Type 1 Type 12
375 mm 420 mm
- -
350 mm 402 mm
130 mm 242 mm
170 mm 242 mm
190 mm 242 mm
110 mm 215 mm
205 mm 195 mm
220 mm 195 mm
207 mm -
222 mm -
8.0 mm 8.25 mm
ø11 mm ø12 mm
ø5.5 mm ø6.5 mm
9 mm 9 mm
7.0 kg 13.5/14.2 kg
3
