5. General Specifications

Mains supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply voltage
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≤ 7.5 kW
Switching on input supply L1, L2, L3 (power-ups) ≥ 11 kW
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100.000 RMS sym-
metrical Amperes, 240/500/600/ 690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency (0.25-75 kW)
Output frequency (90-560 kW)
Output frequency in Flux Mode (FC 302 only)
Switching on output
Ramp times
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Starting torque (Variable torque)
Overload torque (Variable torque)
*Percentage relates to the nominal torque.
Digital inputs:
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
Pulse frequency range
(Duty cycle) Min. pulse width
Input resistance, R
Safe stop Terminal 37
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Nominal input current at 24 V
Nominal input current at 20 V
2)
2)
i
3)
(Terminal 37 is fixed PNP logic):
MG.33.A9.02 - VLT is a registered Danfoss trademark
5. General Specifications
FC 301: 380-480 V / FC 302: 380-500 V ±10%
FC 302: 525-690 V ±10%
3.0 % of rated supply voltage
≥ 0.9 nominal at rated load
near unity (> 0.98)
maximum 2 times/min.
maximum 1 time/min.
overvoltage category III/pollution degree 2
0 - 100% of supply voltage
FC 301: 0.2 - 1000 Hz / FC 302: 0 - 1000 Hz
maximum 160% for 60 sec.
maximum 180% up to 0.5 sec.
maximum 160% for 60 sec.
maximum 110% for 60 sec.
maximum 110% for 60 sec.
FC 301: 4 (5) / FC 302: 4 (6)
18, 19, 27
200-240 V ±10%
50/60 Hz
0 - 800 Hz
0 - 300 Hz
Unlimited
0.01 - 3600 sec.
*
*
*
*
1) 4)
, 29 , 32, 33,
PNP or NPN
0 - 24 V DC
< 5 V DC
> 10 V DC
> 19 V DC
< 14 V DC
28 V DC
0 - 110 kHz
4.5 ms
approx. 4 kΩ
0 - 24 V DC
< 4 V DC
>20 V DC
50 mA rms
60 mA rms
