3.3.5. Access to Control Terminals
All terminals to the control cables are located
underneath the terminal cover on the front of
the frequency converter. Remove the terminal
cover with a screwdriver.
Remove front-cover to access control termi-
nals. When replacing the front-cover, please
28
Bussmann Bussmann Bussmann
Type RK1 Type J Type T
KTS-R10 JKS-10 JJS-10
KTS-R20 JKS-20 JJS-20
KTS-R30 JKS-30 JJS-30
KTS-R40 JKS-40 JJS-40
KTS-R50 JKS-50 JJS-50
KTS-R60 JKS-60 JJS-60
KTS-R80 JKS-80 JJS-80
KTS-R100 JKS-100 JJS-100
KTS-R125 JKS-150 JJS-150
KTS-R150 JKS-150 JJS-150
FWH-220 -
FWH-250 -
KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
KLSR fuses from LITTEL FUSE may substitute KLNR fuses for 240 V frequency converters.
L50S fuses from LITTEL FUSE may substitute L50S fuses for 240 V frequency converters.
A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency convert-
ers.
A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency convert-
ers.
MG.33.A9.02 - VLT is a registered Danfoss trademark
VLT
SIBA Littel fuse
Type RK1 Type RK1
5017906-01 KLS-R10
0
5017906-02 KLS-R20
0
5012406-03 KLS-R30
2
5014006-04 KLS-R40
0
5014006-05 KLS-R50
0
5014006-06 KLS-R60
3
2028220-10 KLS-R80
0
2028220-12 KLS-R100
5
2028220-12 KLS-R125
5
2028220-15 KLS-R150
0
- 2028220-20 L50S-225
0
- 2028220-25 L50S-250
0
Illustration 3.10: A2 and A3 enclosures
ensure proper fastening by applying a torque
of 2 Nm.
®
