3. How to Install

3.1.1. About How to Install
This chapter covers mechanical and electrical installations to and from power terminals and control
card terminals.
Electrical installation of
Guide.
3.1.2. How to Get Started
FC 300 AutomationDrive is designed to ach-
ieve a quick and EMC-correct installation by
following the steps described below.
Mechanical Installation
•
Electrical Installation
•
•
•
•
Quick setup
•
•
•
Frame size is depending on enclosure type,
power range and mains voltage
options
is described in the relevant Operating Instructions and Design
Read the safety instructions before installing the unit.
Mechanical mounting
Connection to Mains and Protecting
Earth
Motor connection and cables
Fuses and circuit breakers
Control terminals - cables
Local Control Panel, LCP
Automatic Motor Adaptation, AMA
Programming
MG.33.A9.02 - VLT is a registered Danfoss trademark
Illustration 3.1: Diagram showing basic installa-
tion including mains, motor, start/stop key, and
potentiometer for speed adjustment.
3. How to Install
3
