Proline Promag 50H, 53H
Endress+Hauser
Clamp DIN 32676
1.4404 / 316L
5*H**-0***********
L
Tri-Clamp L14 AM7
1.4404 / 316L
5*H**-1***********
L
Coupling SC DIN 11851
1.4404 / 316L
5*H**-2***********
L
Coupling DIN 11864-1
Aseptic threaded adapter, Form A
1.4404 / 316L
5*H**-3***********
L
Sensor Fits to
DN Piping
[mm] DIN 11850
40 42 × 2
50 54 × 2
65 70 × 2
80 85 × 2
100 104 × 2
• – Fitting length for DN 40 to 65 = (2 × L) + 136 mm
– Fitting length for DN 80 to 100 = (2 × L) + 196 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
A0005539
measuring tube and process connection (di) into account!
Sensor Fits to
DN DN Piping
[mm] [inch] OD
40 1½" 38.1 × 1.65
50 2" 50.8 × 1.65
65 – 63.5 × 1.65
80 3" 76.2 × 1.65
100 4" 101.6 × 1.65
• – Fitting length for DN 40 to 65 = (2 × L) + 136 mm
– Fitting length for DN 80 to 100 = (2 × L) + 196 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
A0005543
measuring tube and process connection (di) into account!
Sensor Fits to
DN Piping
[mm] DN 11850
40 42 × 2
50 54 × 2
65 70 × 2
80 85 × 2
100 104 × 2
• – Fitting length for DN 40 to 65 = (2 × L) + 136 mm
– Fitting length for DN 80 to 100 = (2 × L) + 196 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
A0005540 measuring tube and process connection (di) into account!
Sensor Fits to
DN Piping
[mm] DN 11850
40 42 × 2
50 54 × 2
65 70 × 2
80 85 × 2
100 104 × 2
• – Fitting length for DN 40 to 65 = (2 × L) + 136 mm
– Fitting length for DN 80 to 100 = (2 × L) + 196 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
A0005545
measuring tube and process connection (di) into account!
di G D
[mm] [mm] [mm] [mm]
38 50.5 92 61.5
50 64.0 105 61.5
66 91.0 121 68.0
81 106.0 147 68.0
100 119.0 168 68.0
di G D
[mm] [mm] [mm]
34.8 50.4 92
47.5 63.9 105
60.2 77.4 121
72.9 90.9 147
97.4 118.9 168
di G D
[mm] [mm] [mm]
38 Rd 65 × 1/6" 92
50 Rd 78 × 1/6" 105
66 Rd 95 × 1/6" 121
81 Rd 110 × 1/6" 147
100 Rd 130 × 1/6" 168
di G D
[mm] [mm] [mm]
38 Rd 65 × 1/6" 92
50 Rd 78 × 1/6" 105
66 Rd 95 × 1/6" 121
81 Rd 110 × 1/6" 147
100 Rd 130 × 1/6" 168
L LK
[mm]
71.0
83.5
100.0
121.0
141.5
L LK
[mm] [mm]
68.8 71.0
68.8 83.5
68.8 100.0
68.8 121.0
68.8 141.5
L LK
[mm] [mm]
72 71.0
74 83.5
78 100.0
83 121.0
92 141.5
L LK
[mm] [mm]
71 71.0
71 83.5
76 100.0
82 121.0
90 141.5
