Proline Promag 50H, 53H
Weight
Measuring tube specifications
Endress+Hauser
Nominal diameter
Compact version (DIN)
[mm]
[inch]
[kg]
2
1/12"
5.2
4
1/8"
5.2
8
3/8"
5.3
15
½"
5.4
25
1"
5.5
40
1½"
6.5
50
2"
9.0
65
–
9.5
80
3"
19.0
100
4"
18.5
• Transmitter (compact version): 3.4 kg (7.5 lbs)
• Weight data valid for standard pressure ratings and without packaging material.
Nominal diameter
[mm]
[inch]
2
1/12"
4
1/8"
8
3/8"
15
½"
–
1"
25
–
40
1½"
50
2"
65
–
80
3"
100
4"
1)
Pressure rating depends on the process connection and the seals used.
2)
Internal diameter of process connections.
Remote version (without cable; DIN)
Sensor
[lbs]
[kg]
[lbs]
11.5
2.0
4
11.5
2.0
4
11.7
2.0
4
11.9
1.9
4
12.1
2.8
6
14.3
4.5
10
19.8
7.0
15
20.9
7.5
17
41.9
17.0
37
40.8
16.5
36
1)
Pressure rating
EN (DIN)
[bar]
PN 16 / PN 40
PN 16 / PN 40
PN 16 / PN 40
PN 16 / PN 40
PN 16 / PN 40
PN 16 / PN 40
PN 16
PN 16
PN 16
PN 16
PN 16
Transmitter (wall-mount housing)
[kg]
[lbs]
6
13
6
13
6
13
6
13
6
13
6
13
6
13
6
13
6
13
6
13
2)
Internal diameter
PFA
[mm]
[inch]
2.25
0.09
4.5
0.18
9.0
0.35
16.0
0.63
22.6
0.89
26.0
1.02
35.3
1.39
48.1
1.89
59.9
2.36
72.6
2.86
97.5
3.84
43
