Endress+Hauser Proline Promag 50H Manual page 26

26
Sensor, remote version DN 2 to 25 (1/12 to 1")
Dimensions in SI units
DN L A
2
4
8 86 127
15
25
Total length depends on the process connections.
All dimensions in [mm]
Dimensions in US units
DN L A
1/12"
1/8"
3/8" 3.39 5.00
½"
1"
Total length depends on the process connections.
All dimensions in [inch]
A
L
B C D
70 75 55 136
B C D
2.76 2.95 2.17 5.35
Proline Promag 50H, 53H
B
X1
di
K
E F K X1
43
43
191 43 M6 × 4
43
56
E F K X1
1.69
1.69
7.52 1.69 M6 × 4
1.69
2.20
Endress+Hauser
A0005536
di
2.25
4.5
9.0
16.0
26.0
di
0.09
0.18
0.35
0.63
0.89
