Proline Promag 50H, 53H
Endress+Hauser
Process connections orderable only as accessories with aseptic gasket seal (DN 15)
Tri-Clamp L14 AM17
1.4404 / 316L
DKH**-HF**
L
Ground rings (accessories for PVDF flanges / PVC adhesive fitting) (DN 2 to 25 / 1/12 to 1")
Ground ring
1.4435/316L, Alloy C-22, Tantalum
DK5HR – ****
0.5 0.5
1.9 1.9
3.4 3.4
4.5 4.5
Sensor Fits to
DN Piping
[mm] OD
15 Tube 25.4 × 1.65
(ODT 1")
• Fitting length = (2 × L) + 86 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
measuring tube and process connection (di) into account!
A0005555
Sensor
DN
[mm] [mm]
2 to 8
15
25 (1" ANSI)
25 (DIN)
A0005568
di G
[mm] [mm]
22.1 50.4
di B C
[mm] [mm]
9.0 22.0 17.6
16.0 29.0 24.6
22.6 36.5 31.2
26.0 39.0 34.6
L H × B
[mm] [mm]
28.5 62 × 42
D
[mm]
33.9
33.9
43.9
43.9
35
