Endress+Hauser Proline Promag 50H Manual page 38

38
Sensor, remote version DN 40 to 100 (1½ to 4")
Dimensions in SI units
DN L A
40 140
50 140
65 140 125
80 200
100 200
Total length depends on the process connections.
All dimensions in [mm]
Dimensions in US units
DN L A
1½" 5.51
2" 5.51
4.92
3" 7.87
4" 7.87
Total length depends on the process connections.
All dimensions in [inch]
A
X2
L
B C D E
64.5 151.5
77.0 164.0
70 75 77.0 164.0
101.5 188.5
101.5 188.5
B C D E
2.54 5.96
3.03 6.46
2.76 2.95
4.00 7.42
4.00 7.42
Proline Promag 50H, 53H
B
di
K
F K X2
216 129 M8 × 4
241 154 M8 × 4
241 154 M8 × 6
290 203 M12 × 4
290 203 M12 × 6
F K X2
8.50 5.08 M8 × 4
9.49 6.06 M8 × 4
11.4 7.99 M12 × 4
11.4 7.99 M12 × 6
Endress+Hauser
A0005535
di
35.3
48.1
59.9
72.6
97.5
di
1.39
1.89
2.86
3.84
