34
Flange DIN 11864-2
Aseptic grooved flange, Form A
1.4404 / 316L
5*H**-4***********
L
Coupling SMS 1145
Threaded adapter; 1.4404 / 316L
5*H**-5***********
L
Process connections orderable only as accessories with O-ring seal (DN 2 to 25 / 1/12 to 1")
Exernal pipe thread
1.4404 / 316L
DKH**-GD**
S
L
Internal pipe thread
1.4404 / 316L
DKH**-GC**
S
L
Sensor Fits to
DN Piping
[mm] DIN 11850
2 to 8 Tube 13 × 1.5
(DN 10)
15 Tube 19 × 1.5
(DN 15)
25 (DIN) Tube 29 × 1.5
(DN 25)
• Fitting length = (2 × L) + 86 mm
•If pigs are used for cleaning, it is essential to take the inside diameters of
measuring tube and process connection (di) into account!
A0005559
Sensor Fits to SMS 1145
DN Piping Diameter
[mm] OD
25 1"
(1" ANSI)
• Fitting length = (2 × L) + 86 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
measuring tube and process connection (di) into account!
A0005564
Sensor Fits to
DN NP
[mm] internal thread
2 to 8 NPT 3/8"
15 NPT ½"
25 (1" ANSI) NPT 1"
• Fitting length = (2 × L) + 86 mm
A0005563
Sensor Fits to
DN NP
[mm] external thread [mm] [inch] [mm] [mm] [mm]
2 to 8 NPT 3/8"
15 NPT ½"
25 NPT 1"
(1" ANSI)
• Fitting length = (2 × L) + 86 mm
A0005565
Proline Promag 50H, 53H
di G L LK
[mm] [mm] [mm] [mm] [mm]
10 54 48.5 37
16 59 48.5 42
26 70 48.5 53
di G
[mm] [mm] [mm]
25 22.6 Rd 40 × 1/6"
di G L
[mm] [inch] [mm]
10 3/8" 50
16 ½" 50
25 1" 55
di G D L
8.9 3/8" 22 45
16.0 ½" 27 45
27.2 1" 40 51
Endress+Hauser
M H × B
[mm]
9 62 × 42
9 62 × 42
9 72 × 55
L H × B
[mm] [mm]
30.8 72 × 55
S H × B
[mm] [mm]
15.5 62 × 42
20.0 62 × 42
25.0 72 × 55
S H × B
[mm]
13 62 × 42
14 62 × 42
17 72 × 55
