Endress+Hauser Proline Promag 50H Manual page 32

32
Adhesive fitting
PVC
5*H**-R/S***********
L
Process connections with aseptic gasket seal (DN 2 to 25 / 1/12 to 1")
Weld socket for DIN
1.4404 / 316L
5*H**-U***********
L
Weld socket for ODT/SMS
1.4404 / 316L
5*H**-V***********
L
Clamp ISO 2852, Fig. 2
1.4404 / 316L
5*H**-W***********
L
Sensor Fits to
DN Pipe
[mm] [mm] [inch]
2 to 8 ½" [inch]
2 to 8 20 × 2 [mm]
(DIN 8062)
15 20 × 2 [mm]
(DIN 8062)
• Fitting length = (2 × L) + 86 mm
• The requisite ground rings can be ordered as accessories
(Order No. DK5HR-****).
A0005566
Sensor Fits to
DN Piping
[mm] DIN 11850
2 to 8 14 × 2
15 20 × 2
25 (DIN) 30 × 2
• Fitting length = (2 × L) + 86 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
measuring tube and process connection (di) into account!
A0003870
Sensor Fits to
DN Piping
[mm] ODT/SMS
2 to 8 12.7 × 1.65
15 19.1 × 1.65
25 (1" ANSI) 24.5 × 1.65
• Fitting length = (2 × L) + 86 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
measuring tube and process connection (di) into account!
A0003871
Sensor Fits to
piping
DN ISO 2037 /
[mm] BS 4825-1
25 (1" ANSI) Tube 24.5 × 1.65
• Fitting length = (2 × L) + 86 mm
• If pigs are used for cleaning, it is essential to take the inside diameters of
measuring tube and process connection (di) into account!
A0005560
Proline Promag 50H, 53H
di G L
[mm] [mm] [mm]
21.5 27.3 38.5
20.2 27.0 38.5
20.2 27.0 28.0
di G L
[mm] [mm] [mm]
9 14 23.3
16 20 23.3
26 30 23.3
di G L
[mm] [mm] [mm]
9.0 12.7 16.1
16.0 19.1 16.1
22.6 25.4 16.1
Clamp di G L
ISO 2850
Diameter
[mm] [mm] [mm] [mm]
25 22.6 50.5 44.3 72 × 55
Endress+Hauser
H × B
[mm]
62 × 42
62 × 42
62 × 42
H × B
[mm]
62 × 42
62 × 42
72 × 55
H × B
[mm]
62 × 42
62 × 42
72 × 55
H × B
[mm]
