Proline Promag 50H, 53H
Endress+Hauser
Flange
10K / JIS B2220; PVDF
5*H**-J***********
L
External pipe thread
ISO 228/ DIN 2999; 1.4404 / 316L
5*H**-K***********
S
L
Internal pipe thread
ISO 228/ DIN 2999; 1.4404 / 316L
5*H**-L***********
S
L
Hose connection
1.4404 / 316L
5*H**-M/N/P***********
L
Sensor Fits to
DN Flange
[mm] B2220
2 to 8 ND 15
15 ND 15
25 (DIN) ND 25
• Fitting length = (2 × L) + 86 mm
• The requisite ground rings can be ordered as accessories
(Order No. DK5HR-****).
A0005567
Sensor Fits to
DN Internal thread
[mm] [inch]
2 to 8 R 3/8"
15 R ½"
25 (1" ANSI) R 1"
• Fitting length = (2 × L) + 86 mm
A0005563
Sensor Fits to
DN External thread
[mm] [inch]
2 to 8 Rp 3/8"
15 Rp ½"
25 (1" ANSI) Rp 1"
• Fitting length = (2 × L) + 86 mm
A0005565
Sensor Fits to
DN Inside diameter
[mm] [inch]
2 to 8 13
15 16
25 19
• Fitting length = (2 × L) + 86 mm
A0005562
di G L LK
[mm] [mm] [mm] [mm] [mm]
16 95 57 70
16 95 57 70
27.2 125 57 90
di G L S
[mm] [inch] [mm] [mm]
10 3/8" 40 10.1
16 ½" 40 13.2
25 1" 42 16.5
di G D L
[mm] [inch] [mm] [mm] [mm]
9 3/8" 22 45
16 ½" 27 45
27.2 1" 40 51
di LW L
[mm] [mm] [mm]
10.0 13 49
12.6 16 49
16.0 19 49
M H × B
[mm]
15 62 × 42
15 62 × 42
19 72 × 55
H × B
[mm]
62 × 42
62 × 42
72 × 55
S H × B
[mm]
13 62 × 42
14 62 × 42
17 72 × 55
H × B
[mm]
62 × 42
62 × 42
62 × 42
