30
Flange
20K / JIS B2220; 1.4404 / 316L
5*H**-F***********
L
Flange
PN 16 / EN 1092-1 (DIN 2501); PVDF
5*H**-G***********
L
Flange
Cl. 150 / ANSI B16.5; PVDF
5*H**-H***********
L
Sensor Fits to
DN Flange
[mm] B2220
2 to 8 ND 15
15 ND 15
25 (DIN) ND 25
• Fitting length = (2 × L) + 86 mm
A0005551
Sensor Fits to
DN Flange
[mm] EN 1092-1
(DIN 2501)
2 to 8 DN 15
15 DN 15
25 (DIN) DN 25
• Fitting length = (2 × L) + 86 mm
• Fitting length to DVGW (200 mm)
• The requisite ground rings can be ordered as accessories
(Order No. DK5HR-****).
A0005567
Sensor Fits to
DN Flange
[mm] ANSI B16.5
2 to 8 ½"
15 ½"
25 (DIN) 1"
• Fitting length = (2 × L) + 86 mm
• The requisite ground rings can be ordered as accessories
(Order No. DK5HR-****).
A0005567
Proline Promag 50H, 53H
di G L LK
[mm] [mm] [mm] [mm] [mm]
15 95 67 70
16 95 67 70
26 125 67 90
di G L LK
[mm] [mm] [mm] [mm] [mm]
16 95 57 65
16 95 57 65
27.2 115 57 85
di G L LK
[mm] [mm] [mm] [mm] [mm]
16 95 57 60
16 95 57 60
27.2 115 57 79
Endress+Hauser
M H × B
[mm]
15 62 × 42
15 62 × 42
19 72 × 55
M H × B
[mm]
14 62 × 42
14 62 × 42
14 72 × 55
M H × B
[mm]
16 62 × 42
16 62 × 42
16 72 × 55
