Basic Parameters Configuration - gefran ADV200 Instruction Manual

The following drive configurations are required:
•

Basic parameters configuration

• Digital I/O
• Encoders
• Field bus
4.2.1 Basic parameters configuration
After loading the default application parameters (Load default, PAR 11100), the basic drive parameters are
configured.
Table 2 shows the configurations loaded.
PAR MENU
552 DRIVE CONFIG
556 DRIVE CONFIG
752 RAMPS
650 REFERENCES
1000 COMMANDS
1004 COMMANDS
1010 COMMANDS
1018 COMMANDS
1020 COMMANDS
1022 COMMANDS
1314 DIGITAL OUTPUT
4452 WORD DECOMP
4500 ALARM CONFIG
Flying Shear for Roll Forming machines – Instruction manual
PARAMETER
PARAMETER
Regulation mode
Control mode select
Ramp out zero src
Dig speed ref 2
Commands remote sel
Enable/disable mode
Commands safe start
Digital Enable src
Digital Start src
Fast Stop src
Digital Output 3 src
Word decomp src
Fault reset src
Table 2: Parameters loaded using Load Default
SETTING
Flux vector CL
Speed
One
Dig spd ref1
Digital
Off
On
Pad 1
Pad 1
Off
Pad 2
Dig word decomp
Null
