Command mapping word
The word sent by the PLC containing the commands is written in the Dig word decomp parameter (PAR
4450). The different function commands are linked to the word bits by selecting the appropriate "bitxx decomp
mon".
WORD
WORD DECOMP
DECOMP
BIT NUMBER
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Flying Shear for Roll Forming machines – Instruction manual
[HEX]
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
0x0100
0x0200
0x0400
0x0800
0x1000
0x2000
0x4000
0x8000
Table 5: Command mapping word
DESCRIPTION
Enable
Fast Stop
Jog -
Jog +
Auto
Homing
Home sens
Imm cut
Blade close
Blade open
Virtual line
Virtual blade
Reset pos mat
Not used
Not used
Not used
