4 Sizing and commissioning

4.1 Machine Data

The data in table 1 must be known before commissioning the shear. This table can be used as a reminder and
completed before or after commissioning.
NAME
Metric wheel advancement
Trolley advancement shift
Usable length for the shear
Maximum trolley return speed.
Maximum acceleration
Maximum deceleration
Synchronization time before cutting
Cutting time
Cutting lenght
Flying Shear for Roll Forming machines – Instruction manual
UNIT OF
VALUE
MEASURE
*
*
m
m/s
m/s 2
m/s 2
s
s
m
Table 1: Machine data
PARAMETER
Line Kmec (PAR 11804),
menu LINE /
Trolley Kmec (PAR 11702),
menu TROLLEY /
Trolley limit pos (PAR 11704),
menu TROLLEY /
Max spd bck (PAR 11012),
menu TROLLEY /
Trolley acc (PAR 11710),
menu TROLLEY /
Trolley dec (PAR 11712),
menu TROLLEY /
Sync time (PAR 11604),
menu AUTO /
Cut time (PAR 11706),
menu TROLLEY /
Cut request (PAR 11800),
menu LINE /
