A.3 Open the System
Remove the cover to gain access to the system. See Figure A–2.
Figure A–2 Opening the System Cabinet
2
1
3
PK1021a-99
1. Unlock the top cover .
2. Loosen the captive screw at the top of the bulkhead .
3. Push down on the lever to the right of the screw and pull it out,
perpendicular to the system.
4. Slide the cover toward the back of the system . Lift it off.
A-4 DS10 Console Reference
