Device name — The name and model of the device as recorded in the
device's firmware.
Device type — Lists the function of the device in the system.
Revision — The revision level of the device signifies the number of
times it has been updated by the manufacturer.
Physical slot — Lists the actual PCI slot number to which the device is
attached.
Figure 3–9 PCI Slots
PCI Slot 4
PCI Slot 3
PCI Slot 2
32 Bit
PCI Slot 1
You can find additional detail about any of the PCI devices listed in the
Advanced PCI Information screen. Follow this procedure to view this screen:
1. Press Enter to enable selection in the device list.
2. Use the arrow keys to select the device for which you want additional detail.
3. Press Enter, and the detail is displayed.
4. Press Escape to return to the table of PCI devices.
The Advanced PCI Information screen is shown in Figure 3–10.
64 Bit
64 Bit
64 Bit
PK1045-99
AlphaBIOS Console 3-13
