APCI-1032, APCI-1564 and APCI-2032
WARNING!
The supply lines must be installed safely against mechanical
loads.
4.3
Versions
The boards are available in the following versions:
APCI-1032: 32 digital inputs
Input voltage
APCI-2032: 32 digital outputs
Output voltage
APCI-1564: 32 digital inputs and 32 digital outputs
WARNING for the APCI-1564!
When all inputs are connected, the temperature of the printed
circuit card increases.
Make sure that the maximum supply voltage of 26 V is not exceeded. Please
consider the given Limit values. (See below)
Input voltage
Output voltage
4.4
Limit values
Max. altitude: ............................................ 2000 m
Operating temperature: ............................. 0 to 60°C
Storage temperature: ................................. -25 to 70°C
Relative humidity at indoor installation
50% at +40 °C
80% at +31 °C
Minimum PC requirements:
PCI BIOS from Version 1.0
APCI-1032 APCI-1032-12 APCI-1032-5
24 V
12 V on request 5 V on request
APCI-2032
APCI-2032-5
24 V
5 V on request
APCI-1564
APCI-1564-5
24 V
5 V on request
24 V
5 V on request
Technical data
