DEFINITION OF APPLICATION
1.1
Intended use
The boards APCI-1032, APCI-1564 and APCI-2032 must be inserted in a PC with PCI
5V/32-bit slots which is used as electrical equipment for measurement, control and
laboratory pursuant to the norm EN 61010-1 (IEC 61010-1). The used personal
computer (PC) must fulfil the requirements of IEC 60950-1 or EN 60950-1 and 55022
or IEC/CISPR 22 and EN 55024 or IEC/CISPR 24.
The use of the boards APCI-1032, APCI-1564 and APCI-2032 in combination with
external screw terminal panels requires correct installation according to IEC 60439-1 or
EN 60439-1 (switch cabinet / switch box).
1.2
Usage restrictions
The boards APCI-1032, APCI-1564 and APCI-2032 must not to be used as safety
related part (SRP).
The boards must not be used for safety related functions, for example for emergency
stop functions.
The boards APCI-1032, APCI-1564 and APCI-2032 must not be used in potentially
explosive atmospheres.
The boards APCI-1032, APCI-1564 and APCI-2032 must not be used as electrical
equipment according to the Low Voltage Directive 2006/95/EC.
1.3
General description of the board
Data exchange between the APCI-1032, APCI-1564 and APCI-2032 boards and the
peripheral is to occur through a shielded cable. This cable must be connected to the 37-
pin SUB-D male connector of the boards.
The board are used for processing digital signals (See Limit values):
the board APCI-1032 has 32 input channels, in 5 V, 12 V or
-
24 V version
the board APCI-1564 has 32 input channels and 32 output channels
-
in 5 V or 24 V version
the board APCI-2032 has 32 output channels, in 5 V or 24 V version.
-
An external 24 V supply voltage is necessary to run the output channels.
The screw terminal panel PX901 and the relay board PX8500 allow connecting the 24
V supply voltage through a shielded cable
The use of the board APCI-1032, APCI-1564 and APCI-2032 in combination with
external screw terminal panel or relay boards is to occur in a closed switch cabinet.
The installation is to be effected competently. Check the shielding capacity of the PC
housing and of the cable prior to putting the device into operation.
Definition of Application
