APCI-1032, APCI-1564 and APCI-2032
Buttons:
Edit:
Selection of the highlighted board with the different parameters set in the text boxes.
Set:
Sets the parametered board configuration. The configuration should be set before you
save it.
Cancel:
Reactivates the former parameters of the saved configuration.
Default:
Sets the standard parameters of the board.
More information (not available for the boards with ADDIPACK)
You can change the board specific parameters like the identifier string, the COM
number, the operating mode of a communication board, etc...
If your board does not support these information, you cannot activate this button.
ADDIDriver Board Manager:
Under Edit/ADDIDriver Board Manager you can check or change the current settings of
the board set through the ADDEVICE Manager.
ADDevice Manager starts and displays a list of all resources available for the virtual
board.
Test registration:
Controls if there is a conflict between the board and other devices installed in the PC. A
message indicates the parameter which has generated the conflict. If no conflict has
occurred, "Test of device registration OK" is displayed.
Deinstall registration:
Deinstalls the registrations of all boards listed in the table and deletes the entries of the
boards in the Windows Registry.
Print registration:
Prints the registration parameter on your standard printer.
Quit:
Quits the ADDIREG program.
