14.2.3 Status Code in Generic Data Mode

(This table is valid only in Generic Data Mode).
Code Condition
0x00 Invalid Transaction
Counter Updated
0x01 Frame Error
0x02 Offline Timeout
Counter Updated
0x03 Buffer Overrun
0x04 Other Error
0x1F No Error
Note: Conditions of type "Error" will eventually be followed by a "No Error" condition when the cause
no longer is detected. Conditions of type "Warning" are however considered informational and may not
necessarily be followed by a "No Error" condition later on.
Anybus Communicator PROFINET User Manual
Type Data Description
Error Counter The number of invalid transactions (i.e. received transac-
tions which does not match any of the consume-transac-
tions defined in the sub-network configuration) has
increased.
Warning - End character is enabled, but a message delimiter timeout
occurs prior to receiving it.
Error Counter The of number of timed out consume-transactions has
increased.
See also...
- "Consume Transactions" on page 33 (Offline timeout
time)
Warning - A node returned more data than expected - or - the gateway
was unable to finish processing a message prior to receiv-
ing a new one.
Error - Undefined error
Warning - No errors
