14.2 Status Register Contents (Gateway to Control
System)

14.2.1 General Information

The Status Register is (if enabled) located at 0x000–0x001 and constitutes a bit-field as follows:
bit(s) Name
15 Send
(SR_HS_SEND)
14 Confirm
(SR_HS_CONFIRM)
13 Data Valid
(Master Mode and DF1
Master Mode Only)
12... 8 Status Code
7... 0 Data
Note: Internally, this is treated as a Motorola-format word (i.e. MSB first). If the higher level network
uses a different byte order, the upper and lower bytes will appear swapped.

14.2.2 Status Codes in Master Mode and DF1 Master Mode

(This table is valid only in Master Mode and DF1 Master Mode).
Code Condition
0x00 Retransmission
Counter Updated
0x01 Single Node Missing
0x02 Multiple Nodes Missing Error
0x03 Buffer Overrun
0x04 Other Error
0x1F No Error
Note: Conditions of type "Error" will eventually be followed by a "No Error" condition when the cause
has been resolved. Conditions of type "Warning" are however considered informational and may not
necessarily be followed by a "No Error" condition later on.
Anybus Communicator PROFINET User Manual
Description
These bits control the handshaking towards the fieldbus control system.
See also...
- "Handshaking Procedure" on page 62
- "Control Register Contents (Control System to Gateway)" on page 66
This bit is set when all transactions have been executed successfully at least once.
Once set, it will not change.
1:Data Valid
0:Data not Valid
Note: This bit is not used in Generic Data Mode.
This field holds the last status report from the gateway.
See also...
- "Status Codes in Master Mode and DF1 Master Mode" on page 64
- "Status Code in Generic Data Mode" on page 65
Type Data
Warning Counter
Error Slave address
Number of nodes Multiple nodes are missing.
Warning Slave address
Error Slave address
Warning -
Control and Status Registers 64
Description
The number of retransmissions on the sub-
network has increased. If this problem per-
sists, this may eventually trigger a Single- or
Multiple Node(s) Missing condition.
A single node is missing.
A node returned more data than expected.
Undefined error
No errors
Doc: HMSI-27-309, Rev. 3.11
