9.4 Node Parameters
To gain access to the parameters described in this section, select a node in the navigation section. For
more information about nodes, see "Nodes" on page 27.
Parameter
Checksum
Slave Address
Type
9.5 Services
Services are commands that can be stored and reused. The user configures each slave with services that
can be issued from the master. A total of 50 services are allowed.
The Anybus Communicator supports a selection of DF1 commands. When the gateway is going to ex-
ecute a service, it automatically chooses the appropriate DF1 command(s) that are used to perform the
service on the selected DF1 node type.
Anybus Communicator PROFINET User Manual
Description
Selects the type of checksum on the network.
The value entered here sets the node address.
The PLC type of the slave
DF1 Protocol Mode 49
Valid Settings
BCC
CRC (default)
0-254
PLC-5
SLC500
MicroLogix
Doc: HMSI-27-309, Rev. 3.11
