- Page 1 How to configure an EtherNetIP adapter with RSLogix 5000.doc SCM-7032-029 Rev 2.03 How to configure an EtherNet/IP adapter module with RSLogix 5000 Saved: 2008-03-05 HMS Industrial Networks AB Page 1 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 2: Document History
Rev 2.03 More info about the network and products For further information about the Anybus products, please consult the HMS homepage, www.anybus.com. The latest manuals, EDS-files etcetera can be downloaded from that location. For more information concerning the EtherNet/IP network the Open EtherNet/IP Vendor Organization has a webpage. -
Page 3: Table Of Contents
Anybus configuration..........................13 5.1. IP settings............................13 5.2. I/O configuration..........................15 5.3. Communicator configuration ......................16 5.4. X-gateway configuration ........................18 Testing ..............................20 6.1. Monitoring the tag...........................20 Saved: 2008-03-05 HMS Industrial Networks AB Page 3 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... -
Page 4: Applicable Anybus Products
2.10 Interface Appendix Power supply 24VDC n.a. Configuration cables n.a. n.a. Null modem cable (Supplied with the n.a. n.a. Anybus X-gateway) Saved: 2008-03-05 HMS Industrial Networks AB Page 4 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... -
Page 5: Solution Overview
Rev 2.03 Solution overview This application note describes how to configure an Anybus EtherNet/IP adapter module with a Rockwell PLC using RSLogix 5000. Below you can find an overview of the system described in this document. Other nodes may be attached to the network, but are not necessary. -
Page 6: Ethernet/Ip Configuration
Then add the Ethernet I/O module. Right click on the I/O configuration directory in the navigation list to the left as seen below. Figure 3 Adding the Ethernet module. Saved: 2008-03-05 HMS Industrial Networks AB Page 6 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... - Page 7 Figure 4 Selecting the type of module. Then enter the desired settings and press finish. Figure 5 Configuring the settings for the Ethernet module. Saved: 2008-03-05 HMS Industrial Networks AB Page 7 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 8: Ethernet/Ip Network Configuration
Now a dialogue window will appear. In this dialogue window, select “Generic Ethernet module” and press Figure 7 Selecting the Generic Ethernet Module. Saved: 2008-03-05 HMS Industrial Networks AB Page 8 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... - Page 9 IP address that we have configured for the module, here 10.10.14.225 . The next step is to press next. Saved: 2008-03-05 HMS Industrial Networks AB Page 9 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
- Page 10 Now the Anybus-S Slave has been added to the I/O configuration in RSLogix 5000. The main screen will look as follows. Figure 10 The main screen when the configuration is completed. Saved: 2008-03-05 HMS Industrial Networks AB Page 10 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 11: Downloading The Configuration To The Plc
Who Active command. Select the desired communication path as seen below. Figure 11 Configuring the communication path. Select “Go Online” from the “Communications” menu. Figure 12 Opening the online window. Saved: 2008-03-05 HMS Industrial Networks AB Page 11 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... - Page 12 If there are any errors, a warning triangle will be present on the Anybus-S Slave in the I/O configuration listing. Double click the module to view any error that is reported. Saved: 2008-03-05 HMS Industrial Networks AB Page 12 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 13: Anybus Configuration
5.1. IP settings Make sure each node on the network has a unique IP address. The IP settings of the Anybus EtherNet/IP modules can be configured in various ways. It is recommended to use the Anybus IPconfig tool for configuring the IP-settings. The Anybus IPconfig tool can be used to configure the IP settings of all Anybus EtherNet/IP modules. - Page 14 Note for the Anybus CompactCom: The Anybus CompactCom can be configured by the network configuration object. For further instructions see the respective manual or appendix. Saved: 2008-03-05 HMS Industrial Networks AB Page 14 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 15: I/O Configuration
Note for the Anybus Communicator and the Anybus X-gateway: The configuration of the Anybus Communicator and the Anybus X-gateway is described in separate sections below. Saved: 2008-03-05 HMS Industrial Networks AB Page 15 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... -
Page 16: Communicator Configuration
The Anybus Communicator is configured for generic data mode; all other values are left at their defaults. Figure 18 Configuring the Communicator. Saved: 2008-03-05 HMS Industrial Networks AB Page 16 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc... - Page 17 1000 ms and the offline timeout time to 2000 ms. Saved: 2008-03-05 HMS Industrial Networks AB Page 17 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 18: X-Gateway Configuration
Figure 20 Configuring the connection in the HyperTerminal. Make sure the settings are identical to those shown in the window above. Alternatively download a HyperTerminal session file from the HMS website , double click on it and select COM port. - Page 19 How to configure an EtherNetIP adapter with RSLogix 5000.doc SCM-7032-029 Rev 2.03 Figure 22 The X-gateway configuration. Saved: 2008-03-05 HMS Industrial Networks AB Page 19 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
-
Page 20: Testing
Output tags . If the network is correctly configured the corresponding Input Tags will obtain the respective value. The values are depending on the application, in this case the values are just examples. Saved: 2008-03-05 HMS Industrial Networks AB Page 20 (20) Filename: How to configure an EtherNetIP adapter with RSLogix 5000.doc...
