Selecting the "Module" tab will reveal additional properties:
Item
Size of logbuffer
Firmware Download
Factory Restore
Block Configuration
Create Error log
View
•
Toolbar
Enables/disables the toolbar icons at the top of the main win-
dow.
•
Status Bar
Enables/disables the status bar at the bottom of the main win-
dow.
Help
•
Contents/Search For Help On...
Opens a built-in browser window with a link to the Anybus
support website.
•
About...
Displays general information about the gateway and the current
version of ACM.
Anybus Communicator PROFINET User Manual
Description
By default, the Data Logger can log up to 512 entries in each direction. If necessary, it
is possible to specify a different number of entries (valid settings range from 1...512).
Click "Apply" to validate the new settings. See also "Data Logger" on page 58.
Download firmware to the embedded fieldbus interface.
Warning: Use with caution.
Restores the gateway firmware to the
original state (does not affect the embedded fieldbus interface).
When selected, the downloaded configuration will not be executed by the gateway.
Warning: Use with caution.
Creates an error log file
Navigating ACM 22
Doc: HMSI-27-309, Rev. 3.11
