Tools
•
Port
Select the COM-port used for the configuration of the gateway.
•
Upload configuration from
Communicator RS232/422/485
Upload the configuration from the gateway to ACM.
•
Download configuration to
Communicator RS232/422/485
Download the current configuration to the gateway.
•
Start Logging
Start the Data Logger (see "Data Logger" on page 58).
Note that when the Data Logger is active, this menu entry is changed to "Stop Logging".
•
Options
This will open the following window:
Item
Warning on Delete
Warning on Unsaved
Configuration
Show Wizard when
"New" menu is selected
Select language
Anybus Communicator PROFINET User Manual
Description
A confirmation dialog is displayed each time something is deleted.
A confirmation dialog is displayed when closing ACM with unsaved data.
The Wizard is displayed each time a new configuration is created.
Selects which language to use. The new setting will be active the next time the pro-
gram is launched.
Navigating ACM 21
Doc: HMSI-27-309, Rev. 3.11
