11.2.2 Toolbar Icons

The toolbar features icons for the most commonly used functions.
• Start Node & Stop Node
These icons corresponds to the functions in the "Node" menu.
See also "Node" on page 56.
• Select Command & Send Command
These icons corresponds to the functions in the "Command" menu.
See also "Command" on page 56.
• Resume Refresh & Stop Refresh
The data displayed in the Monitor Section will normally be refreshed au-
tomatically (cyclically).
Click on "Stop" to stop automatic data refresh. Data will now only be
refreshed if you click "Refresh" (see below).
Press "Resume" to resume automatic refreshing of data.
• Refresh
Refreshes the data displayed in the Monitor Section.
Anybus Communicator PROFINET User Manual
Node Monitor 57
Start Stop
Select Send
Stop Resume
Refresh
