5 About Adjustable Frequency Drive Programming

5.1 Introduction

The adjustable frequency drive is programmed for its
application functions using parameters. Parameters are
accessed by pressing either [Quick Menu] or [Main Menu]
on the LCP. (See 4 User Interface for details on using the
LCP function keys.) Parameters may also be accessed
through a PC using the MCT 10 Set-up Software (see
5.6.1 Remote Programming with MCT 10 Set-up Software).
The quick menu is intended for initial start up (Q2-** Quick
Set Up). Data entered in a parameter can change the
options available in the parameters following that entry.
The main menu accesses all parameters and allows for
advanced adjustable frequency drive applications.

5.2 Programming Example

Here is an example for programming the adjustable
frequency drive for a common application in open-loop
using the quick menu.
•
This procedure programs the adjustable
frequency drive to receive a 0–10 V DC analog
control signal on input terminal 53
•
The adjustable frequency drive will respond by
providing 6-60 Hz output to the motor propor-
tional to the input signal (0–10 V DC = 6–60 Hz)
Select the following parameters using the navigation keys
to scroll to the titles and press [OK] after each action.
1. 3-15 Reference Resource 1
14.7%
References
3-15 Reference Resource
[1]] Analog input 53
Figure 5.1
VLT ® AutomationDrive Instruction
Manual
0.00A 1(1)
5-1*
®
MG33AL22 - VLT is a registered Danfoss trademark
2. 3-02 Minimum Reference. Set minimum internal
adjustable frequency drive reference to 0 Hz.
(This sets the minimum adjustable frequency
drive speed at 0 Hz.)
14.7%
Analog Reference
3-02 Minimum Reference
0.000 Hz
Figure 5.2
3. 3-03 Maximum Reference. Set maximum internal
adjustable frequency drive reference to 60 Hz.
(This sets the maximum adjustable frequency
drive speed at 60 Hz. Note that 50/60 Hz is a
regional variation.)
14.7%
Analog Reference
3-03 Maximum Reference
50.000 Hz
Figure 5.3
4. 6-10 Terminal 53 Low Voltage. Set minimum
external voltage reference on Terminal 53 at 0 V.
(This sets the minimum input signal at 0 V.)
14.7%
Analog Reference
6-10 Terminal 53 Low
Voltage
0.00 V
Figure 5.4
