Danfoss VLT AutomationDrive FC 300 Instruction Manual page 79

Specifications
For fuse ratings, see 10.3.1 Fuses
1) High overload = 160% torque during 60 s. Normal overload = 110% torque during 60 s.
2) American Wire Gauge.
3) Measured using 16.5 ft. [5 m] shielded motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within
cable conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line). Motors with lower efficiency will also add to the power loss in the
adjustable frequency drive and vice-versa.
If the switching frequency is increased compared to the default setting, the power losses may rise significantly.
LCP and typical control card power consumptions are included. Further options and customer load may add up to 0.04 hp [30 W] to the
losses. (Though typical only 0.005 hp [4W] extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be allowed for (
5) The three values for the max. cable cross-section are for single core, flexible wire and flexible wire with sleeve, respectively.
10 10
10-8
VLT ® AutomationDrive Instruction
Manual
®
MG33AL22 - VLT is a registered Danfoss trademark
▲ ▼
/ 15% (tolerance relates to variety in voltage and
▲ ▼
/ 5%).
