URD-0032CG-4 (DO32C4) - 32 Digital Outputs, (Source)

Outputs per module
Indicators(Logic side )
Output Voltage Range
ON-state voltage drop
ON-State Min. Current
OFF-State Leakage current
Output Signal Delay
Output Current Rating
COMMON Type
Power dissipation
Isolation
Field Power
Wiring
Weight
Module Size
Operating temperature
Unitronics
Items Specification
32 Points Source type
32 Green Output status
Nominal 24VDC
Min. 15VDC to Max. 32VDC
Max. 0.3Vdc @ 25 ºC )77°F( / 0.5Vdc@ 60 ºC )140°F(
Min. 1mA / Channel
Max. 5uA
OFF to ON : 0.3ms maximum
ON to OFF : 0.3ms maximum
Max. 0.3A per channel /Max. 6.0A per unit
32 points / 4 Common
65mA maximum @ 5.0VDC
I/O to Logic : Photocoupler Isolation
Field Power : Non-Isolation
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation: 30mA @ 32VDC
Module connector : HIF3BA-40D-2.54R
63g
12mm x 109mm x 70mm
-40°C to 70°C (-40°F to 158°F)
