2. LED Indicators

LED No. LED Function / Description
0 Output 0
1 Output 1
2 Output 2
3 Output 3
4 Output 4
5 Output 5
6 Output 6
7 Output 7
8 Output 8
9 Output 9
10 Output 10
11 Output 11
12 Output 12
13 Output 13
14 Output 14
15 Output 15
Status
Uni-I/O Status
Field Power Error
Unitronics
LED Color
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
LED
Off
Green
Status Channel Repeat the Green and Off
Indication
Disconnection
Connection
Field power is
Unconnected.
