2. LED Indicators

LED No. LED Function / Description
0 Input 0
1 Input 1
2 Input 2
3 Input 3
4 Input 4
5 Input 5
6 Input 6
7 Input 7
Status
Not Signal,
Normal Operation
On Signal
Normal Operation
On Signal
Normal Operation
Connected External CJC
Unitronics
LED Color
Green
Green
Green
Green
Green
Green
Green
Green
LED
Channel LED Off, CJ LED Off
Channel LED Off, CJ LED Off
Channel LED Off, CJ LED Off
Indication
Input Sensor Open or Input Range Over
Normal Operation
Sensor Connected and Input Range Valid
Normal Operation
Sensor Connected and Input Range Valid
Normal Operation, External CJ enable
