4/19
1. Wiring Diagram
in No.
0
Input 0
2
Input 2
4
Input 4
6
Input l 6
8
Input 8
10
Input 10
12
Input 12
14
Input 14
Common(Sink Oper.0V / Source Oper.24V)
16
18
NC
20
Input 16
22
Input 18
24
Input 20
26
Input 22
28
Input 24
30
Input 26
32
Input 28
34
Input 30
Common(Sink Oper.0V / Source Oper.24V)
36
38
NC
Unitronics
Signal Description
Pin No.
Signal Description
1
Input 1
3
Input 3
5
Input 5
7
Input 7
9
Input 9
11
Input 11
13
Input 13
15
Input 15
Common(Sink Oper.0V Source Oper.24V)
17
19
NC
21
Input 17
23
Input 19
25
Input 21
27
Input 23
29
Input 25
21
Input 27
33
Input 29
35
Input 31
Common(Sink Oper.0V / Source Oper.24V)
37
39
NC
30
