Configuring interfaces to the central BMS
BACnet MS/TP interface
Multistate Value Objects
Property
Object_Identifier
Object_Name
Object_Type
Present_Value
Status_Flags
Event_State
Out_Of_Service
Number_Of_States
State_Text
R: Read Property, W: Write Property, -E: Storage in EEPROM
Instance
Number_
Of_States
1
3
2
15
3
15
PICS_X-AIRCONTROL_v1.0.doc
62
Remark / Value
multistate-value, instance 1 ... 9
MULTISTATE_VALUE (19)
State
IN_ALARM:
FAULT:
OVERRIDDEN:
OUT_OF_SERVICE:
NORMAL (0)
FALSE (0)
Object_Name
"COV-Mode"
"ApplicMode"
"ActApplicMode"
Single room control system FSL‑CONTROL II
0
0
0
0
State
State_Text
1
"Disabled"
2
"Local Broadcast"
3 (initial)
"Global Broadcast"
1 (initial)
"HVAC_NUL"
2
"HVAC_AUTO"
3
"HVAC_HEAT"
4
"HVAC_MRNG_WRMUP"
5
"HVAC_COOL"
6
"HVAC_NIGHT_PURGE"
7
"HVAC_PRE_COOL"
8
"HVAC_OFF"
9
"HVAC_TEST"
10
"HVAC_EMERG_HEAT"
11
"HVAC_FAN_ONLY"
12
"HVAC_FREE_COOL"
13
"HVAC_MAXHEAT"
14
"HVAC_ECONOMY"
15
"HVAC_DEHUMID"
1 (initial)
"HVAC_NUL"
2
"HVAC_AUTO"
3
"HVAC_HEAT"
4
"HVAC_MRNG_WRMUP"
5
"HVAC_COOL"
6
"HVAC_NIGHT_PURGE"
7
"HVAC_PRE_COOL"
8
"HVAC_OFF"
9
"HVAC_TEST"
10
"HVAC_EMERG_HEAT"
11
"HVAC_FAN_ONLY"
12
"HVAC_FREE_COOL"
13
"HVAC_MAXHEAT"
14
"HVAC_ECONOMY"
15
"HVAC_DEHUMID"
- 6 -
RW
R
R
R
R
R
R
R
R
Present_Value
RW-E
RW
R
