Symbol Meaning
Volume flow controller with Compact con-
troller (depends on unit type)
Temperature sensor
Humidity sensor (optional)
Air quality sensor (optional)
SEH Single room exhaust air
SET Single room extract air
SRO Single room outdoor air
SRS Single room supply air
SEC Secondary air
Colour codes
green - Function OK
red - Function not OK
3.2.2 Setting control temperatures and
operating times (commissioning
wizard, or 'assistant')
To set control temperatures and operating times, go to
the main menu and select 'Commissioning assistant' .
On the 'Temperature control' page you can set the con-
trol parameters for cooling (Fig. 19/1) and heating
(Fig. 19/6).
After setting the parameters, select 'Next' to go to the
next page.
